GE Frame 5PA Gas



Offer: GE Frame 5PA Gas Turbine Generator – 26 MW

Manufacturer: General Electric

Condition: Brand New, Never Installed

Technical Specifications:

• Power Output: 26,060 kW (26 Megawatt Hour “MWh”)

• Cycle Type: Simple Cycle

• Fuel Type: Natural Gas

• Combustion System: Dry Low NOx (DLN)

• Efficiency: 27.7% (Heat rate @ site rating: 12,807 BTU/kWh)

• Exhaust Temperature: 850°F

• NOx Emissions: 25 ppmvd at base load

• Rotational Speed: 5100 rpm

• Design Standards: API 616

• Starter Type: Electric Motor Starter

• Gear Reducer: Rated 5100/1800 rpm

• Exhaust System: Side exhaust included

• Fuel System: Natural gas fuel system with operating pressure of 363 PSI

• Fuel Specification: 1028 BTU (20,699 BTU/lb, LHV)

• Generator Type: GE TEWAC

• Generator Rating: 40,000 kVA

• Generator Output: 30,000 kW

• Voltage & Frequency: 13,800V / 3-phase / 60 Hz

• Storage: Stored per GE storage standards

Scope of Supply:

• GE Turbine Skid: (39’ L x 12’ W x 13’ H, 200,000 lbs)

• Generator Skid: (24’ L x 12’ W x 12’ H, 210,000 lbs)

• Inlet System

• Exhaust System

• All Manuals & Drawings

Additional Benefits:

• High Availability & Reliability: Over 350 units sold worldwide with an average fleet availability of 97.56% and reliability of 98.90%.

• Enhanced Fuel Flexibility: No impact on combustor’s operability or integrity.

• Compact Design: Single lift basement engine and auxiliaries for faster installation.

• Long-Term Performance: First commercial unit exceeded 300,000 operating hours.

Pricing:

• Replacement Value Today: $42 Million USD

• Price Offer: $24 Million USD

• REDUCED

• Vendor has received an offer which is being considered since this must be sold

payment to Escrow is how this will be done. Anyone who can meet the same and act first will get this absolute bargain

Buyer will be asked to put 10% into the Escrow account to show they are a serious buyer and financially capable. We will then quickly arrange an inspection. If the turbine is accepted, the 10% becomes down payment on the turbine. If not, the funds will be returned less minor inspection and banking charges.

We have an account set up in the US with reputable Attorneys. All funds go through them and done very legally and correctly.

---

---

---
