M2500 Mobile Gas Turbine Generator



Product Details



Quantity 4

Availability (Lead Time) 0-2 Weeks

Product Location Indonesia

Condition New

Equipment code CFIHOS-30000534

Per Unit Price € 22,950,000.00



Description



Full Technical Specifications



Electrical Power Output



Rated Power Output: ~35–36 MW (at ISO conditions)



Voltage Options: 6.6 kV / 11 kV / 13.8 kV



Frequency: 50 Hz / 60 Hz



Power Factor: 0.8 (Typical)



Efficiency: ~37–40% (Simple Cycle Mode)



Fuel System



Fuel Type: Dual-Fuel (Natural Gas / Liquid Fuel – Diesel, Jet A1, Kerosene)



Fuel Consumption:



Natural Gas: ~9,000 Nm³/h at full load



Liquid Fuel: ~8,200 kg/h at full load



Fuel Pressure Requirement: 350–650 psi (24–45 bar) for Natural Gas



Mechanical & Operational Data



Turbine Type: Aeroderivative Gas Turbine (LM2500)



Rotational Speed: 3,600 RPM (60 Hz) / 3,000 RPM (50 Hz) with Gearbox



Compression Ratio: 18:1 (Approx.)



Exhaust Temperature: ~500–540°C



Exhaust Flow: ~126 kg/s



Startup Time: Less than 10 minutes to full power



Cooling & Lubrication System



Cooling Type: Air-cooled system



Lubrication System: Pressurized Oil Lubrication



Oil Type: Synthetic Turbine Oil (ISO VG 46 or equivalent)



Oil Capacity: ~1,500 liters



Auxiliary Systems



Control System: GE Mark VIe / VI+ Digital Control System



Generator Type: Brushless AC Generator (Synchronous)



Black Start Capability: Optional



NOx Emissions: =25 ppm (DLN combustor with Natural Gas)



Dimensions & Mobility



Mounting Configuration: Trailer-Mounted (Mobile)



Weight: ~100,000 kg (Complete Unit with Trailer)



Dimensions (L × W × H): 13–15m × 3m × 4.2m (Varies by Configuration)



Transport Mode: Road / Rail / Air Cargo (C-5 / Antonov 124 Capable)



Grid & Connection Features



Startup Power Requirement: =500 kW (Battery / Auxiliary Diesel Generator)



Synchronization: Auto-Sync with Grid / Island Mode Operation



Paralleling Capability: Yes, with multiple units for increased capacity



Technical Details



Model Number



TM2500



Usage Hours



00



ISO 15926 Pt 4



7686



PCA RDS Code



RDS820799



CFIHOS ID



CFIHOS-30000534



Fuel type



Natural Gas



Output Power



Up to 35 MW



Speed



3,600 RPM



Direction of Rotation



Counterclockwise



Design Specification



Aeroderivative gas turbine



Normal Operating Temperature



0°C to 40°C



Explosion Protection Gas Group



IIC



Explosion Protection Temperature Class



T6



Explosion Protection Zone



Zone 2



Lower Limit Operating Temperature



-5°C (23°F)



Operation Continuous Intermittent



Continuous Operation



Upper Limit Operating Temperature



50°C (122°F)



Number Of Shafts



1 Shaft



Test Medium



Air



Test Pressure



around 2.0 to 3.0 bar



Turbine Cycle



Open-Cycle Gas Turbine



Insulation Class



Class H
