Bronco All Terrain Tracked Carriers

Bronco All Terrain Tracked Carriers combine outstanding mobility, payload, and protection to deliver tactical maneuverability, war-proven variants, and high survivability for a wide range of missions. Its open architecture allows for quick mission module changes, future tech upgrades, and advanced network capabilities.



Pricing Details

Variant



Recommended Retail Price



UN Discounted Price



Units Ready



ATV (Terrain Vehicle)



£ 745000.- GBP



£ 615000.- GBP



45 units ready



CV (Terrain Command)



£ 755000.- GBP



£ 595000.- GBP



3 units ready



RRV (Terrain Repair Recovery)



£ 795000.- GBP



£ 685000.- GBP



2 units ready



Spares Packages

Inclusive of spare Tracks, Engines, Transmissions, and 2000 lines totaling to over 60,000 pieces.

Savings Package Price: £ 9250000.- GBP

Technical Specifications

Dimensions:

Length: 8.60 m

Width: 2.26 m

Height: 2.30 m (front)

Curb Weight (Prime Mover): 10,000 kg

Payload (Depending on equipment/options): 6,000 kg (growth potential up to 8,000 kg)

Additional payload of 3,000 kg with Trailer

Passengers: 12 (4 front + 8 rear)

Performance:

Maximum Speed: 65 km/h (on road)

Gradient: Hard surface 60% (31°), Deep snow 30% (17°)

Range on roads: 500 km

Swim speed: 4 to 5 kph

Operating Temperature: Maximum + 49°C, Minimum - 46°C

Engine:

Type: Caterpillar C7 (350 BHP)

Power: 240 kW (325 HP) @ 2,200 rpm

Torque: 1,300 Nm @ 1,200 rpm

Transmission: Allison MD3500 (Auto 6-speed)

Cooling: Liquid + Air

Electrical System:

Voltage: 24 V DC

Alternator: 450 A

Protection:

Material: Armour steel - Direct fire 7.62 AP up to STANAG level 4 with add-on protection

Add-on mine protection classified

CE protection RPG armour system

Important to know:



Regarding these ATV units being offered, I appreciate the cost vs. capability difference. Technically, nothing stops your client from going directly to manufacturers, but like many large defense companies, they do not have available ATV machines ready for 12-18 months and would most certainly not pay our offered price. My items are ready now and can be viewed with a day’s notice. Pending paperwork and license agreements could be completed in a matter of 3 weeks. While my cost is higher than the Spartan option, it includes upgraded technology and better performance for advanced terrains. Spartan machines from pre-1985 will generally be cheaper than those from the early 2010s, but this may result in potential breakdowns or component failures in the CRV models due to wear and tear.



Terms & Conditions:



Payment Terms: A 15% deposit is required to secure the sale and activate the pre-delivery services and inspections.

Inspection & Verification: Viewing either by SGS or direct Buyer is agreed upon receiving confirmed deposit, and a final inspection will be conducted before shipment. If, at the inspection, the vehicles are not in the offered condition the deposit is paid back. In case the inspection is OK and the client does not conclude the contract (7 days after inspection) the deposit is kept. If the client closes the contract, the deposit is put in balance.

Delivery Schedule: Immediately available

Warranty: The equipment has a warranty of 6 months or 1,000 hours, whichever occurs



first, as long as the equipment and main components are maintained according to the



periodic maintenance tasks contained in the Maintenance Manual(s) supplied by Seller.
